Product Details
- Place of Origin: Cangzhou city,Hebei province, China
- Brand Name: XIANQIAO
- Model Number: ZL29TM000348.1-2012(ZC-VLV-(B) 0.6/1kV)
Mr Wang Jian
Tel: 86-317-3870255
Fax: 86-317-3870255
Mobile: 86-18631771999
E-mail: dfxljt@163.com
| 序号 | 规格 | 导体结构 | 导体外径(mm) | 绝缘厚度(mm) | 包带规格(mm) | 护套厚度(mm) | 参考外径(mm) | 参考重量(kg/km) |
|---|---|---|---|---|---|---|---|---|
| 1 | 1×10 | 7/1.35 | 4.05 | 1.0 | 20×0.20 | 1.4 | 9.8 | 119.0 |
| 2 | 1×16 | 7/1.66 | 5.10 | 1.0 | 20×0.20 | 1.4 | 10.8 | 146.2 |
| 3 | 1×25 | 7/2.14 | 6.42 | 1.2 | 20×0.20 | 1.4 | 12.5 | 203.2 |
| 4 | 1×35 | 7/2.52 | 7.56 | 1.2 | 20×0.20 | 1.4 | 13.7 | 247.0 |
| 5 | 2×10 | 7/1.35 | 4.05 | 1.0 | 20×0.20 | 1.8 | 17.0 | 356.0 |
| 6 | 2×16 | 7/1.66 | 5.10 | 1.0 | 20×0.20 | 1.8 | 19.0 | 448.6 |
| 7 | 2×25 | 7/2.14 | 6.42 | 1.2 | 25×0.20 | 1.8 | 22.4 | 638.9 |
| 8 | 2×35 | 7/2.52 | 7.56 | 1.2 | 25×0.20 | 1.8 | 24.8 | 789.1 |
| 9 | 3×10 | 7/1.35 | 4.05 | 1.0 | 20×0.20 | 1.8 | 18.0 | 403.6 |
| 10 | 3×16 | 7/1.66 | 5.10 | 1.0 | 25×0.20 | 1.8 | 20.2 | 513.3 |
| 11 | 3×25 | 7/2.14 | 6.42 | 1.2 | 25×0.20 | 1.8 | 23.8 | 734.3 |
| 12 | 3×35 | 7/2.52 | 7.56 | 1.2 | 25×0.20 | 1.8 | 26.4 | 911.2 |
| 13 | 4×10 | 7/1.35 | 4.05 | 1.0 | 25×0.20 | 1.8 | 19.6 | 482.0 |
| 14 | 4×16 | 7/1.66 | 5.10 | 1.0 | 25×0.20 | 1.8 | 22.1 | 619.0 |
| 15 | 4×25 | 7/2.14 | 6.42 | 1.2 | 25×0.20 | 1.8 | 26.2 | 897.9 |
| 16 | 4×35 | 7/2.52 | 7.56 | 1.2 | 25×0.20 | 1.8 | 29.1 | 1117.4 |
| 17 | 5×10 | 7/1.35 | 4.05 | 1.0 | 25×0.20 | 1.8 | 21.4 | 577.4 |
| 18 | 5×16 | 7/1.66 | 5.10 | 1.0 | 25×0.20 | 1.8 | 24.1 | 739.8 |
| 19 | 5×25 | 7/2.14 | 6.42 | 1.2 | 25×0.20 | 1.8 | 28.7 | 1083.2 |
| 20 | 5×35 | 7/2.52 | 7.56 | 1.2 | 30×0.20 | 1.9 | 32.1 | 1365.6 |
- Place of Origin: Cangzhou city,Hebei province, China
- Brand Name: XIANQIAO
- Model Number: ZL29TM000348.1-2012(ZC-VLV-(B) 0.6/1kV)
Mr Wang Jian
Tel: 86-317-3870255
Fax: 86-317-3870255
Mobile: 86-18631771999
E-mail: dfxljt@163.com
| 序号 | 规格 | 导体结构 | 导体外径(mm) | 绝缘厚度(mm) | 包带规格(mm) | 护套厚度(mm) | 参考外径(mm) | 参考重量(kg/km) |
|---|---|---|---|---|---|---|---|---|
| 1 | 1×10 | 7/1.35 | 4.05 | 1.0 | 20×0.20 | 1.4 | 9.8 | 119.0 |
| 2 | 1×16 | 7/1.66 | 5.10 | 1.0 | 20×0.20 | 1.4 | 10.8 | 146.2 |
| 3 | 1×25 | 7/2.14 | 6.42 | 1.2 | 20×0.20 | 1.4 | 12.5 | 203.2 |
| 4 | 1×35 | 7/2.52 | 7.56 | 1.2 | 20×0.20 | 1.4 | 13.7 | 247.0 |
| 5 | 2×10 | 7/1.35 | 4.05 | 1.0 | 20×0.20 | 1.8 | 17.0 | 356.0 |
| 6 | 2×16 | 7/1.66 | 5.10 | 1.0 | 20×0.20 | 1.8 | 19.0 | 448.6 |
| 7 | 2×25 | 7/2.14 | 6.42 | 1.2 | 25×0.20 | 1.8 | 22.4 | 638.9 |
| 8 | 2×35 | 7/2.52 | 7.56 | 1.2 | 25×0.20 | 1.8 | 24.8 | 789.1 |
| 9 | 3×10 | 7/1.35 | 4.05 | 1.0 | 20×0.20 | 1.8 | 18.0 | 403.6 |
| 10 | 3×16 | 7/1.66 | 5.10 | 1.0 | 25×0.20 | 1.8 | 20.2 | 513.3 |
| 11 | 3×25 | 7/2.14 | 6.42 | 1.2 | 25×0.20 | 1.8 | 23.8 | 734.3 |
| 12 | 3×35 | 7/2.52 | 7.56 | 1.2 | 25×0.20 | 1.8 | 26.4 | 911.2 |
| 13 | 4×10 | 7/1.35 | 4.05 | 1.0 | 25×0.20 | 1.8 | 19.6 | 482.0 |
| 14 | 4×16 | 7/1.66 | 5.10 | 1.0 | 25×0.20 | 1.8 | 22.1 | 619.0 |
| 15 | 4×25 | 7/2.14 | 6.42 | 1.2 | 25×0.20 | 1.8 | 26.2 | 897.9 |
| 16 | 4×35 | 7/2.52 | 7.56 | 1.2 | 25×0.20 | 1.8 | 29.1 | 1117.4 |
| 17 | 5×10 | 7/1.35 | 4.05 | 1.0 | 25×0.20 | 1.8 | 21.4 | 577.4 |
| 18 | 5×16 | 7/1.66 | 5.10 | 1.0 | 25×0.20 | 1.8 | 24.1 | 739.8 |
| 19 | 5×25 | 7/2.14 | 6.42 | 1.2 | 25×0.20 | 1.8 | 28.7 | 1083.2 |
| 20 | 5×35 | 7/2.52 | 7.56 | 1.2 | 30×0.20 | 1.9 | 32.1 | 1365.6 |
